Store and transfer the brake fluid, transfer the hydraulic energy generated by the clutch master cylinder to the clutch slave cylinder, convert the hydraulic energy into mechanical energy through the slave cylinder, and push the clutch fork to separate from the bearing, so as to realize the clutch separation.
EMAIL:
info@orlete.comphone:
8613645184293Structure：EPDM/Synthetic fiber braided layer(/Middle rubber /Synthetic fiber braided layer)/EPDM
Medium：Polar brake fluid.(Non-petroleum based)
Temperature：-40～120℃
Standard：GB 16897
| TYPE | I.D mm |
O.D mm |
Max W.P MPa |
Min B.P MPa |
Minimum Bending Radius mm |
Max expansion ml/m |
|
| 6.9MPa | 10.3MPa | ||||||
| Y0510A | 5 | 10.5 | 3 | 34.5 | 50 | ≤1.81 | ≤2.36 |
| Y0513A | 5 | 13 | 3 | 34.5 | 65 | ≤1.81 | ≤2.36 |
| Y0715A | 7.5 | 15 | 3 | 34.5 | 75 | ≤3.41 | ≤4.27 |
